Sliding Window
Sliding is the simplest kind of motion — the sash moves sideways, never projecting in or out, which makes it the natural choice wherever space is at a premium. Precision stainless steel rollers carry the panel with a quiet, effortless glide, while ultra-slim aluminium profiles hold the glass area as large as possible, so the view stays open even when the window is closed.
None of that ease is accidental. Multi-chamber thermally broken profiles, multi-layer EPDM seals, and concealed drainage channels are engineered to keep the system performing against air, water, dust, and wind, holding its integrity through daily use across thousands of cycles. It’s a system built for luxury villas, high-rise apartments, and commercial developments where natural light and reliable, low-maintenance operation matter equally.
1. Smooth Sliding Operation
Precision-engineered stainless steel rollers ensure effortless, quiet, and reliable operation, holding that ease with minimal maintenance over time.
2. Slim European Sightlines
Ultra-slim aluminium profiles maximize glass area, letting in abundant natural daylight and keeping outdoor views uninterrupted.
3. Thermally Broken Aluminium Profiles
Multi-chamber profiles with glass fibre reinforced polyamide thermal breaks significantly reduce heat transfer, improving both energy efficiency and indoor comfort.
4. Space-Saving Design
Sliding sashes move horizontally without projecting inward or outward, making the system ideal for spaces where clearance is limited.
5. Large Glass Panels
The system is engineered to support large-format glazing while maintaining excellent structural stability and smooth operation.
6. Superior Weather Protection
Multi-layer EPDM seals, brush seals, and concealed drainage channels provide excellent resistance to air infiltration, water penetration, dust, and wind.
Glazing spans double glazing at 24 to 32 mm and triple glazing at 36 to 52 mm, both available with Low-E coating, argon fill, and warm edge spacers, extending into clear, low-iron, toughened, laminated, solar control, reflective, acoustic, frosted, decorative, and optional smart glass. Finishes follow the collection's established range — matte, fine texture, and metallic powder coating, anodized aluminium, wood grain sublimation, dual colour finishes, and custom RAL colours — so every window sits comfortably within a broader façade palette.
Hardware and configuration are built around flexibility as much as ease. Heavy-duty sliding carriages, flush and lockable handles, optional soft-close mechanisms, anti-lift devices, insect screen integration, and optional motorized sliding support two, three, four, and six panel configurations, fixed and sliding combinations, corner sliding, pocket sliding, floor-to-ceiling, and multi-track systems. That range suits luxury villas, high-rise apartments, hotels, offices, educational and healthcare facilities, retail developments, and premium commercial projects alike.
Technical Specifications
| Specification | Details |
|---|---|
| System Type | Thermally Broken Aluminium Sliding Window System |
| Opening Style | Horizontal Sliding |
| Available Tracks | 2 Track, 3 Track, 4 Track |
| Sash Configuration | 2, 3, 4 or 6 Panels |
| Frame Depth | 70–120 mm |
| Sash Depth | 32–45 mm |
| Visible Sightline | 35–80 mm |
| Aluminium Alloy | EN AW-6060 T66 / EN AW-6063 T6 |
| Aluminium Profile Thickness | 1.8–2.5 mm |
| Thermal Break | 24–34 mm Polyamide (Optional Depending on System) |
| Maximum Sash Height | Up to 3,000 mm |
| Maximum Sash Width | Up to 2,000 mm |
| Maximum Sash Weight | Up to 300 kg |
| Surface Finish | Qualicoat Powder Coating, Anodized, Wood Grain Sublimation |
| Standard Colours | RAL 7016, RAL 9005, RAL 9016, Bronze, Champagne, Custom RAL Colours |
Glazing Options
- Double Glazing: 24–32 mm, Low-E coating, argon gas filled, warm edge spacer
- Triple Glazing: 36–52 mm, superior thermal performance, enhanced acoustic insulation
- Glass types: clear, low-iron, toughened safety, laminated safety, solar control, reflective, acoustic, frosted, decorative, smart glass (optional)
Thermal Performance
| Performance | Value |
|---|---|
| Whole System U-Value (Uw) | As low as 1.2 W/m²K |
| Glass U-Value (Ug) | As low as 0.5 W/m²K |
| Thermal Break | 24–34 mm Polyamide |
Weather Performance
| Test | Performance |
|---|---|
| Air Permeability | EN 12207 – Class 4 |
| Water Tightness | EN 12208 – Up to E900 |
| Wind Resistance | EN 12210 – Up to Class C5 |
| Acoustic Performance | Up to 43 dB |
| Thermal Insulation | EN ISO 10077 Compliant |
Security Features
Multi-point locking system, anti-lift sash protection, reinforced aluminium frame, laminated safety glazing compatibility, toughened safety glazing compatibility, concealed locking hardware, child safety restrictors (optional), RC2 security configurations available.
Hardware Components
Stainless steel rollers, heavy-duty sliding carriages, multi-point locking system, flush handles, lockable handles, soft-close mechanism (optional), anti-lift devices, concealed drainage system, smart lock compatibility, insect screen integration, motorized sliding operation (optional).
Available Configurations
Two panel sliding window, three panel sliding window, four panel sliding window, six panel sliding window, fixed + sliding combination, corner sliding window, pocket sliding window (project specific), floor-to-ceiling sliding window, multi-track sliding system, custom architectural configurations.
European Standards Compliance
| Standard | Description |
|---|---|
| EN 14351-1 | Windows and External Pedestrian Doorsets |
| EN 12207 | Air Permeability |
| EN 12208 | Water Tightness |
| EN 12210 | Wind Resistance |
| EN ISO 10077 | Thermal Performance |
| EN 1191 | Mechanical Durability |
| EN 13115 | Mechanical Strength of Windows |
| EN 1279 | Insulating Glass Units |
| EN 1096 | Coated Glass |
| EN 12150 | Toughened Safety Glass |
| EN 14449 | Laminated Safety Glass |
| EN 356 | Security Glazing |
