Awning Window
Hinged at the top and opening outward from the bottom, an awning window does something few others can: it lets air move through a space even while the weather outside is doing its worst. The form is quiet and contemporary, its slim profiles holding clean architectural lines without asking for attention, letting daylight fill the opening the way it was meant to.
Behind that quiet performance is real engineering. Multi-chamber thermally broken profiles, triple gasket sealing, and precision European friction stays keep the window sealed, steady, and easy to operate through long-term use. It is a system built for luxury villas, contemporary residences, and commercial developments where ventilation, protection from the elements, and architectural restraint are all expected in the same window.
1. Thermally Broken Aluminium Profiles
Multi-chamber profiles with glass fibre reinforced polyamide thermal breaks significantly reduce heat transfer, holding energy efficiency steady across every season.
2. Contemporary European Design
Slim aluminium profiles and clean architectural lines sit comfortably against both modern and traditional building styles, letting natural daylight move through without interruption.
3. Excellent Ventilation
The top-hinged, outward-opening design allows continuous airflow into a space while still helping protect the interior from light rain.
4. Superior Weather Resistance
Triple EPDM gasket sealing, concealed drainage, and precision compression hardware protect against air infiltration, water penetration, and wind pressure, all without a visible seam.
5. Smooth & Reliable Operation
Premium European friction stays, concealed hinges, and locking hardware deliver effortless opening and secure closing, built to hold that ease over long-term use.
6. Enhanced Security
Multi-point locking, reinforced aluminium construction, and compatibility with laminated safety glazing provide dependable protection without altering the window’s clean profile.
Glazing runs from double glazing at 24 to 44 mm to triple glazing at 44 to 60 mm, both available with Low-E coating, argon fill, and warm edge spacers, and extends into clear, low-iron, laminated, toughened, solar control, reflective, acoustic, frosted, and decorative glass for projects that call for it. Finishes follow the collection's established range — matte, fine texture, and metallic powder coating, anodized aluminium, wood grain sublimation, dual colour finishes, and custom RAL colours — keeping every surface considered rather than decorative.
Hardware and configuration are built around the same flexibility. Concealed hinges, heavy-duty friction stays, restrictor arms, child safety restrictors, soft-close hardware, and optional motorized opening with smart home compatibility support single or multiple awning window combinations, fixed and awning pairings, floor-to-ceiling systems, curtain wall integration, corner configurations, and ribbon window systems. That range makes the system equally suited to luxury villas, contemporary homes, offices, hotels, educational and healthcare buildings, and premium commercial developments.
Technical Specifications
| Specification | Details |
|---|---|
| System Type | Thermally Broken Aluminium Awning Window |
| Opening Style | Top-Hung Outward Opening |
| Frame Depth | 70–75 mm |
| Sash Depth | 75–80 mm |
| Aluminium Alloy | EN AW-6060 T66 / EN AW-6063 T6 |
| Aluminium Thickness | 2.0–3.0 mm |
| Thermal Break | 34–42 mm Glass Fibre Reinforced Polyamide (PA66 GF25) |
| Maximum Window Height | Up to 1,800 mm |
| Maximum Window Width | Up to 1,600 mm |
| Maximum Sash Weight | Up to 1,600 mm |
| Surface Finish | Qualicoat Powder Coating, Anodized, Wood Effect Sublimation |
| Standard Colours | RAL 7016, RAL 9005, RAL 9016, Bronze, Champagne, Custom RAL Colours |
Glazing Options
- Double Glazing: 24–44 mm, Low-E coating, argon gas filled, warm edge spacer
- Triple Glazing: 44–60 mm, superior thermal performance, enhanced acoustic insulation
- Glass types: clear, low-iron, laminated safety, toughened safety, solar control, reflective, frosted, decorative, acoustic
Thermal Performance
| Performance | Value |
|---|---|
| Whole Window U-Value (Uw) | As low as 0.8 W/m²K |
| Glass U-Value (Ug) | As low as 0.5 W/m²K |
| Thermal Break | 34–42 mm Polyamide |
Weather Performance
| Test | Performance |
|---|---|
| Air Permeability | EN 12207 – Class 4 |
| Water Tightness | EN 12208 – Up to E1200 |
| Wind Resistance | EN 12210 – Up to Class C5 |
| Acoustic Performance | Up to 46 dB |
| Thermal Insulation | EN ISO 10077 Compliant |
Security Features
Multi-point locking system, concealed locking hardware, reinforced aluminium construction, laminated safety glazing compatibility, toughened safety glazing compatibility, anti-lift hardware, RC2 security configurations available.
Hardware Options
Concealed hinges, heavy-duty friction stays, stainless steel friction hinges, multi-point locking, lockable window handles, restrictor arms, child safety restrictors, soft-close hardware, motorized opening systems (optional), smart home automation compatibility.
Available Configurations
Single awning window, multiple awning window combinations, fixed + awning combination, floor-to-ceiling window systems, curtain wall integrated awning windows, corner window configurations, ribbon window systems, custom architectural sizes.
European Standards Compliance
| Standard | Description |
|---|---|
| EN 14351-1 | Windows and External Pedestrian Doorsets |
| EN 12207 | Air Permeability |
| EN 12208 | Water Tightness |
| EN 12210 | Wind Resistance |
| EN ISO 10077 | Thermal Performance |
| EN 1191 | Mechanical Durability |
| EN 13115 | Mechanical Strength of Windows |
| EN 1279 | Insulating Glass Units |
| EN 1096 | Coated Glass |
| EN 12150 | Toughened Safety Glass |
| EN 14449 | Laminated Safety Glass |
| EN 356 | Security Glazing |
