Fibre Shading
Less weight doesn’t mean less shade. Precision-formed Glass Fibre Reinforced Polymer blades deliver the same solar control as aluminium at a fraction of the mass, cutting the structural load a façade or retrofit has to carry while still controlling glare and solar heat gain with the same precision as a metal louvre.
That weight saving comes with a material advantage metal can’t match. Fibre composites resist corrosion, salt spray, moisture, and UV exposure far beyond conventional aluminium, making the system a natural fit for coastal buildings and harsh environments where finishes on metal would eventually fail. It’s engineered for commercial towers, airports, transportation hubs, and landmark developments where long façade runs and low maintenance both matter.
1. Advanced Fibre Composite Technology
Manufactured using premium Glass Fibre Reinforced Polymer (GFRP/GRP) or Fibre Reinforced Composite (FRC), providing exceptional mechanical strength with significantly reduced weight compared to steel or aluminium.
2. Superior Solar Shading
Precision-designed fibre blades reduce direct solar heat gain, control glare, and optimize natural daylight, improving indoor comfort and reducing cooling energy demand.
3. Lightweight Construction
The low self-weight of composite materials minimizes structural loading, making the system ideal for large façade applications and retrofit projects.
4. Exceptional Corrosion Resistance
Unlike conventional metals, fibre composites are highly resistant to corrosion, salt spray, moisture, chemicals, and UV exposure, making them suitable for coastal and harsh environmental conditions.
5. Minimal Maintenance
The non-corrosive, UV-stable surface requires very little maintenance while maintaining long-term structural integrity and colour stability.
6. Contemporary Architectural Design
Available in multiple blade profiles, sizes, colours, and custom geometries to complement modern architectural façades.
Blade profile is chosen for the performance and the look a façade needs. Aerofoil blades give superior aerodynamic performance with excellent solar control; rectangular blades hold a contemporary, uniform façade line with high structural rigidity; elliptical blades improve airflow and daylight management with a more premium finish; and fully custom profiles support project-specific geometries, decorative features, and corporate branding. Blades run from 100 to 500 mm wide and 6 to 25 mm thick, up to 6,000 mm in length, mounted on an aluminium or stainless steel support framework.
Fire performance can be specified where required, with fire retardant resin systems, low smoke emission formulations, self-extinguishing composite technology, and project-specific fire classification available to meet applicable building regulations. Configuration covers horizontal sun louvres, vertical sun screens, full building façade shading, window sun control, balcony privacy screens, roof edge and mechanical equipment screening, car park screening, and fully custom façade installations — suited to commercial towers, hotels, airports, transportation hubs, educational and healthcare facilities, and landmark architectural developments alike.
Technical Specifications
| Specification | Details |
|---|---|
| System Type | Fibre Reinforced Architectural Shading System |
| Material | Glass Fibre Reinforced Polymer (GFRP/GRP) or Fibre Reinforced Composite (FRC) |
| Installation | Horizontal, Vertical or Inclined |
| Blade Profiles | Aerofoil, Rectangular, Elliptical, Custom |
| Blade Width | 100–500 mm |
| Blade Thickness | 6–25 mm |
| Maximum Blade Length | Up to 6,000 mm |
| Structural Support | Aluminium or Stainless Steel Framework |
| Fasteners | AISI 316 Stainless Steel |
| UV Protection | Integrated UV-Stable Surface Technology |
| Surface Finish | Architectural Gel Coat, Fluoropolymer Coating, Polyurethane Finish |
| Standard Colours | White, Grey, Black, Bronze, Wood Finish, Custom RAL Colours |
| Performance | Details |
|---|---|
| Solar Heat Gain Reduction | High Performance |
| Daylight Optimization | Excellent |
| Energy Efficiency | Reduced Cooling Loads |
| Thermal Stability | Outstanding |
| UV Resistance | Excellent |
Weather Performance
| Performance | Details |
|---|---|
| Corrosion Resistance | Excellent |
| Salt Spray Resistance | Suitable for Marine Environments |
| UV Resistance | Long-Term Colour Stability |
| Moisture Resistance | Non-Corrosive Composite Construction |
| Weather Durability | Extreme Climate Performance |
Fire Performance
Composite materials can be supplied to meet project-specific fire safety requirements. Available options include: fire retardant resin systems, low smoke emission formulations, self-extinguishing composite technology, project-specific fire classification, compliance with applicable building regulations.
Structural Performance
| Performance | Details |
|---|---|
| Strength-to-Weight Ratio | Excellent |
| Wind Resistance | Project Specific Engineering |
| Structural Design | Eurocode-Based Engineering |
| Deflection Control | Engineered to Project Requirements |
| Design Life | Long-Term Exterior Performance |
Hardware Components
Fibre composite louvres, aluminium structural framework, stainless steel mounting brackets, adjustable blade supports, concealed fixing systems, structural connectors, expansion fixings, decorative end caps.
Available Configurations
Horizontal sun louvres, vertical sun screens, building façade shading, window sun control systems, balcony privacy screens, roof edge screening, mechanical equipment screening, car park screening, decorative architectural features, custom façade installations.
European Standards Compliance
| Standard | Description |
|---|---|
| EN 13561 | External Solar Shading Systems – Performance Requirements |
| EN 13659 | External Blinds and Solar Shading Devices |
| EN 13706 | Pultruded Fibre Reinforced Polymer (FRP) Profiles |
| EN ISO 14125 | Fibre Reinforced Plastics – Mechanical Properties |
| EN ISO 4892 | Artificial Weathering & UV Exposure Testing |
| EN ISO 12944 | Corrosion Protection of Structural Components |
| EN ISO 3506 | Stainless Steel Fasteners |
| EN 1990 | Eurocode – Basis of Structural Design |
| EN 1991 | Eurocode 1 – Structural Actions |
| ISO 9001 | Quality Management Systems |
| CE Marking | Compliant with European Construction Products Regulation (CPR), where applicable |
