Aluminium Fixed Window
Some windows aren’t meant to open — they’re meant to disappear. With no moving parts and minimal aluminium sightlines, a fixed window exists purely to hold glass in place, letting large-format glazing carry views and daylight without a single interruption. It’s the simplest architectural gesture there is: transparency, held as still and precisely as possible.
That stillness is also structural strength. Fixed glazing offers exceptional rigidity, making it suited to the largest architectural openings and curtain wall integrations, while thermally broken profiles and high-performance insulated glazing keep energy efficiency high despite the scale. With no hardware to maintain, the system is built for luxury villas, landmark projects, and commercial developments where the window itself is meant to be the least noticeable part of the room.
1. Expansive Glass Panels
The system is designed to accommodate large-format glazing with minimal aluminium sightlines, creating uninterrupted views and abundant natural light.
2. Ultra-Slim European Profiles
Precision-engineered aluminium frames maximize glass surface area while maintaining superior structural strength and elegant aesthetics.
3. Thermally Broken Aluminium Profiles
Multi-chamber profiles with glass fibre reinforced polyamide thermal breaks significantly reduce heat transfer, improving indoor comfort and energy efficiency.
4. Superior Structural Stability
Fixed glazing provides exceptional rigidity, making the system ideal for large architectural openings and curtain wall integrations.
5. Outstanding Energy Efficiency
High-performance insulated glazing minimizes heat loss, reduces solar heat gain, and contributes to lower overall energy consumption.
6. Low Maintenance Design
With no moving components or hardware, the system offers exceptional reliability, a long service life, and minimal maintenance requirements.
Glazing spans double glazing at 24 to 44 mm and triple glazing at 44 to 60 mm, both available with Low-E coating, argon fill, and warm edge spacers, extending into clear, ultra clear low-iron, toughened, laminated, solar control, reflective, acoustic, frosted, decorative, ceramic frit, and optional smart glass. Safety and structure are built in from the frame outward — structural glazing gaskets, EPDM weather seals, pressure plates, and stainless steel fixings support toughened, laminated, structural, and impact-resistant glazing options, with RC2/RC3 security glazing compatibility available where a project requires it.
Configuration ranges from fixed picture windows and floor-to-ceiling glazing to corner fixed windows, ribbon windows, curtain wall integration, structural glazed and frameless-appearance windows, fixed plus operable combinations, and multi-panel fixed windows — all finished in matte, fine texture, and metallic powder coating, anodized aluminium, wood grain sublimation, and custom RAL colours. That range suits luxury villas, high-rise apartments, hotels, offices, educational and healthcare facilities, airports, museums, and landmark architectural projects alike.
Technical Specifications
| Specification | Details |
|---|---|
| System Type | Thermally Broken Aluminium Fixed Window System |
| Opening Style | Fixed (Non-Operable) |
| Frame Depth | 50–120 mm |
| Visible Sightline | 30–70 mm |
| Aluminium Alloy | EN AW-6060 T66 / EN AW-6063 T6 |
| Aluminium Profile Thickness | 1.8–2.5 mm |
| Thermal Break | 24–42 mm Glass Fibre Reinforced Polyamide (PA66 GF25) |
| Maximum Glass Height | Up to 6,000 mm (Project Specific) |
| Maximum Glass Width | Up to 3,500 mm (Project Specific) |
| Maximum Glass Weight | Project Specific |
| Surface Finish | Qualicoat Powder Coating, Anodized, Wood Grain Sublimation |
| Standard Colours | RAL 7016, RAL 9005, RAL 9016, Bronze, Champagne, Custom RAL Colours |
Glazing Options
- Double Glazing: 24–44 mm, Low-E coating, argon gas filled, warm edge spacer
- Triple Glazing: 44–60 mm, superior thermal performance, enhanced acoustic insulation
- Glass types: clear, ultra clear low-iron, toughened safety, laminated safety, solar control, reflective, acoustic, frosted, decorative, ceramic frit, smart glass (optional)
Thermal Performance
| Performance | Value |
|---|---|
| Whole System U-Value (Uw) | As low as 0.8 W/m²K |
| Glass U-Value (Ug) | As low as 0.5 W/m²K |
| Thermal Break | 24–42 mm Polyamide |
Weather Performance
| Test | Performance |
|---|---|
| Air Permeability | EN 12207 – Class 4 |
| Water Tightness | EN 12208 – Up to E1200 |
| Wind Resistance | EN 12210 – Up to Class C5 |
| Acoustic Performance | Up to 48 dB |
| Thermal Insulation | EN ISO 10077 Compliant |
Safety Features
Toughened safety glazing compatibility, laminated safety glazing compatibility, structural glazing compatibility, reinforced aluminium framing, high wind-load resistance, impact-resistant glazing options, security glazing compatibility (RC2 / RC3 project specific).
Hardware Components
Thermally broken aluminium frame, structural glazing gaskets, EPDM weather seals, pressure plates (where applicable), snap-on cover caps, stainless steel fixings, concealed drainage system, structural silicone glazing (optional), curtain wall integration components.
Available Configurations
Fixed picture window, floor-to-ceiling window, corner fixed window, ribbon window, curtain wall integrated window, structural glazed window, frameless glass appearance, fixed + operable combination, multi-panel fixed window, custom architectural configurations.
European Standards Compliance
| Standard | Description |
|---|---|
| EN 14351-1 | Windows and External Pedestrian Doorsets |
| EN 12207 | Air Permeability |
| EN 12208 | Water Tightness |
| EN 12210 | Wind Resistance |
| EN ISO 10077 | Thermal Performance |
| EN 1279 | Insulating Glass Units |
| EN 1096 | Coated Glass |
| EN 12150 | Toughened Safety Glass |
| EN 14449 | Laminated Safety Glass |
| EN 356 | Security Glazing |
| EN 12600 | Pendulum Impact Resistance for Glass |
| CE Marking | Compliant with European Construction Products Regulation (CPR) |
